Weldcraft CS410-25 W-410 Braided Rubber Water-Cooled TIG Torch (1 Torch)

$ 753.84

Weldcraft CS410-25 W-410 Braided Rubber Water-Cooled TIG Torch (1 Torch)





Formerly known as the CS410, the W-410 is a versatile water-cooled torch designed for demanding applications. The W-410 increases amperage output without increasing the torch size, and is engineered for welding satisfaction even in the coldest weather with top of the line technology.



Features:



Simplify Torch Package Installation

  • With the ColorSmart® hose and cable sets that differentiate input water, water/power cable, and gas hoses



D-Handle™ Design

  • Features a self-indexing flat top that allows for torch orientation by feel



Work in Cold Weather

  • With the Tri-Flex® hose and cable assembly that remains flexible to ease handling and extending cable life



Improve High-Frequency Shielding

  • Minimize gas leakages with the double-lip back cap seal





Specifications:



MODEL W-410
RATED OUTPUT
  • DC: 410 A
  • AC: 310 A
DUTY CYCLE 100%
ELECTRODE RANGE .020" - 5/32" (0.5 - 4.0 mm)
APPLICATIONS
  • Aerospace
  • Aluminum fabrication
  • Aluminum ship repair
  • Automotive
  • Exotic material fabrication
  • Light and heavy manufacturing
  • Maintenance and repair
  • Metal fabrication
  • Pipe and tube fabrication
  • Pressure vessel fabrication
  • Shipbuilding
  • Tool and die
  • Tube and pipe
  • Vocational



Consumables:



PART NUMBER PART NAME
18CG Weldcraft TIG Torch Nozzle Insulator
10N21 Weldcraft .020" TIG Collect
10N22 Weldcraft .040" TIG Collect
10N23 Weldcraft 1/16" TIG Collect
10N24 Weldcraft 3/32" TIG Collect
10N25 Weldcraft 1/8" TIG Collect
54N20 Weldcraft 5/32" TIG Collect
10N29 Weldcraft .020" TIG Collect Body
10N30 Weldcraft .040" TIG Collect Body
10N31 Weldcraft 1/16" TIG Collect Body
10N32 Weldcraft 3/32" TIG Collect Body
10N28 Weldcraft 1/8" TIG Collect Body
406488 Weldcraft 5/32" TIG Collect Body
10N50 Weldcraft #4 Alumina Nozzle
10N49 Weldcraft #5 Alumina Nozzle
10N48 Weldcraft #6 Alumina Nozzle
10N47 Weldcraft #7 Alumina Nozzle
10N46 Weldcraft #8 Alumina Nozzle
10N45 Weldcraft #10 Alumina Nozzle
10N44 Weldcraft #12 Alumina Nozzle
